35,000CMH Air Cooler
Target Price: $2,900.00
Evaporative air cooling is a natural and highly efficient method of cooling that relies on the physical process of water evaporation to absorb heat. This eco-friendly technology offers optimal performance.
During the operation of a 35000CMH air cooler, water is systematically drawn from the tank and circulated through evaporative cooling pads, effectively saturating them. A centrifugal fan is then employed to pull hot air from the outside and direct it through the moistened cooling pads.
As a result, the pads efficiently absorb the heat from the air, while simultaneously filtering and cooling it. This process ensures the distribution of filtered and cooled air to the desired space, establishing an efficient and effective cooling system.
The combination of a 35000CMH air cooler and a centrifugal fan guarantees the delivery of powerful and effective cooling.
| MPN | RTF-35B |
| SKU | RTF35B001 |
| Voltage/Freq (V/Hz) | 380/50 |
| Max Air Flow(CMH) | 35,000 |
| Working Current(A) | 15.4 |
| Power (Kw) | 7.5 |
| Physical Size(MM) | 1,780*1,780*1,350 |
| Air Outlet Size(MM) | 728*700 |
| Weight | 450 |
| Water Tank Capacity(L) | 80 |
| Water Consumption(L/H) | 220 |
| Applicable Area(m²) | 200~300 |
Stay Cool, Save Energy
By utilizing RTFANS’s HVLS Fans, air coolers, and other systems, we can establish a comfortable indoor environment, enabling people to rest and work more effectively.
The Best Choice in large industrial plants
As summer rolls around, most people are looking for cost-effective industrial air coolers to keep their spaces cool. Traditional air cooling methods are costly and inefficient when operating and handling extremely high temperatures in large industrial plants. At this time, evaporative air coolers are undoubtedly the best choice.
Evaporative air coolers are economizer coolers that use simple evaporative energy to provide cooling comfort to the user. Fresh filtered air flows through the ducts and cools the space.
More Efficient Cooling System
Installing an evaporative cooler is more expensive than an air conditioner, but provides a more efficient cooling system than traditional air conditioners, and can especially help save on energy bills. If you’re looking for a cooling system for your commercial or industrial building, choosing an industrial evaporative cooler would be a great choice.
High Cooling Efficiency
To ensure high cooling efficiency, turn off the water supply, empty and clean the water tank, and dry the cooling pad during winter or when not in use for a long time. Draining the circulating water from the cooler tank is critical as it prevents the build-up of water that can be easily damaged and corroded.
Cool and Humidify the air by Evaporation
Industrial Evaporative Coolers can cool and humidify the air by evaporation. Evaporative cooling is an energy-efficient and cost-saving solution. The principal places where they can cool down include warehouses, manufacturing plants, workshops, construction sites, hangars, stadiums, loading docks, marquee tents, garages, farms, sporting events, barns, barns, swimming pools or terraces, etc.
Fan Motor
- Adopt low vibration, low noise and high-temperature resistance, corrosion resistance 100% copper core motor;
- Adopt cast iron housing, corrosion resistance and reliable;
- More heavy with better balance and stability under running at high speed.
Fan Blade
- The fan blade is made of carbon fiber composite material, with a patented design;
- which will not deform or break under heavy pressure;
- It has the characteristics of large air volume, high air pressure, low noise and stable operation.
Cooling Pad Assembly
- High evaporation efficiency and quick/fast cooling;
- In line with the RoHS international environmental standard;
- Superb wetting properties without water spatter;
- Strong and self-supporting without deformation, long service life;
- With anti-Algae level 1 to prevent the growth of algae.
Housing Material
- The shell is made of new environmental protection engineering anti-oxidation plastic, which has good toughness, anti-aging and anti-ultraviolet;
- Special reinforcing rib design, more strong and longer life;
- 5 years warranty for the housing of air cooler.
Eaves-type Louver Design
The patented design of the water distribution system makes the water flow evenly distributed on the cooling pad, never clogging, and the cooling effect is more significant.
Mechanical Water Inlet Valve
No extra energy consumption, automatic water replenishment, no blockage, high stability, quality assurance for 100,000 times operation.
Save Energy Cost Up To 30%
Cover 1,000m² + with only 1.5kw!
Big industrial ceiling fans are energy efficient,cost-effective and can provide massive air movement in large industrial and commercial spaces.
LCD Display Control Panel
Easy to operate, with timer, temperature, humidity (optional) control system, fault reminder function, concise and clear.
Frequently Asked Questions
How does an 35,000CMH Air Cooler work?
Water is pumped from a reservoir to wet the cooling pad. After that, a blower or a fan draws warm air from outside and passes it through the damp pad. As the warm air passes through the wet pad, it is cooled through evaporation before being let out into the air.
How much does the 35,000CMH Air Cooler lower the temperature?
The temperature of the air coming out of the equipment depends on the temperature and humidity of the air going in. Also, the constant movement of the air that is created by the blower makes the air released feel 4 to 6-degrees cooler than the actual temperature.
Where are 35,000CMH Air Cooler applicable?
–Factory cooling : This equipment can be used in a single or multiple areas and is recommended for factories that need a lot of cooling and ventilation.
– Warehouse cooling : This system works well even in areas with open roller doors to provide ventilation and a cool working place.
– Shop/retail cooling : It provides an efficient and economical way to cool retail premises
–Restaurant cooling : One of the most important aspects of creating a conducive environment not only for workers but also customers in a hotel is through the cool fresh air and comfortable temperatures.
– Office cooling : An industrial air cooler can be used in open-plan offices or those with a more sophisticated setting.
– School cooling : The equipment offers an economical and effective way of cooling for learning institutions.
–Workshop cooling : This system is exceptionally affordable to install and run. It also works fast and efficiently.
